1 NC/Drive Machine Data 10.94
1.7.1 Channel-specific bits 1, standard assignments
1.7.1 Channel-specific bits 1, standard assignments
M version T version
MD No. 76543210 76543210
5400
to
5405
00000001
:
00000001
00000101
:
00000001
5420
to
5425
00000000
:
00000000
00000000
:
00000000
5440
to
5445
00000000
:
00000000
00000000
:
00000000
5460
to
5465
00000000
:
00000000
00000000
:
00000000
5480
to
5485
00000000
:
00000000
00000000
:
00000000
5500
to
5505
00000001
:
00000001
00000010
:
00000010
5520
to
5525
00000010
:
00000010
00000010
:
00000010
5540
to
5545
00000000
:
00000000
00000000
:
00000000
5560
to
5565
00000000
:
00000000
00000000
:
00000000
5580
to
5585
00000000
:
00000000
1–30 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
