11.92 2 PLC Machine Data
2.2 General PLC machine data for function blocks (DB 61)
2.2 General PLC machine data for function blocks (DB 61)
High byte (DL) Low byte (DR)
DW No.
PLC
MD No.
DW 0
2000
.
.
.
.
.
.
.
.
.
.
.
.
DW 77
2077
DW 78
2078
.
.
.
DW 89
2089
DW 90
2090
DW 91
2091
.
.
.
DW 95
2095
DW 96
2096
.
.
.
DW 119
2119
DW 120
2120
.
.
.
DW139
2139
Machine data words for function blocks (IA)
Reserved for tool management
.
.
.
.
.
.
.
.
.
.
.
.
Reserved for tool management
Reserved for computer link
.
.
.
Reserved for computer link
Reserved for code carrier loading/unloading
Reserved
.
.
.
Reserved
Reserved for computer link
.
.
.
Reserved for computer link
Reserved for tool management
.
.
.
Reserved for tool management
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60
2–5
SINUMERIK 840C (IA)
