06.93 1 NC/Drive Machine Data
1.14 Code table for axis name
1.14 Code table for axis name
Example: 0000 0010=Z
0001 1001=Q1
Bit No.
Extended address
(address number)
Code:
blank = 0000
1 = 0001
2 = 0010
3 = 0011
4 = 0100
5 = 0101
6 = 0110
7 = 0111
8 = 1000
9 = 1001
10 = 1010
11 = 1011
12 = 1100
13 = 1101
14 = 1110
15 = 1111
Address name
Code:
X = 0000
Y = 0001
Z = 0010
A = 0011
B = 0100
C = 0101
U = 0110
V = 0111
W = 1000
Q = 1001
E = 1010
7 456 3 2 1 0
The names in MD 5000, MD 5001 and 568* must not overlap. An identical address name with
different extended address is not considered to be an overlap.
Permissible names for axes, angles, chamfer and radius
A freely assignable address N subordinate block
B freely assignable address O can be confused with 0 (zero)
C freely assignable address P subroutine - number of passes
D tool offset number Q freely assignable address
E freely assignable address R arithmetic parameter
F feed S spindle speed, S function
G G function T tool
H H function U freely assignable address
I interpolation parameter V freely assignable address
J interpolation parameter W freely assignable address
K interpolation parameter X freely assignable address
L subroutine Y freely assignable address
M M function Z freely assignable address
END OF SECTION
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–89
