04.96 1 NC/Drive Machine Data
1.12.2 SI drive machine data
1.12.2 SI drive machine data
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1300 Monitoring cycle 384
(=12 ms)
800 -- 31.25 µ s
1301 Enable safety functions 0 FF03 -- HEX
1302 Axis-specific bits for safety
functions
0 0002 -- --
1316 Motor encoder configuration for
safety functions
0 0003 -- --
1317 Grid spacing linear scale 10 8000 -- µ m
1318 Encoder marks per revolution 2048 100000 -- --
1320 Spindle pitch 10 8388,00 -- mm/rev
1321 Denominator gear unit
Encoder/load
1 8388607 -- --
1322 Numerator gear unit
Encoder/load
1 8388607 -- --
1330 Standstill tolerance 1000 100000 -- µ m or 0.001
degrees
1331 Limit values for safe speed 2000 1000000 -- mm/min or
rev/min
1334 Upper limit value for safe limit
position
10000000
0
2147000000 -- µ m or 0.001
degrees
1335 Lower limit value for safe limit
position
-
10000000
0
2147000000 -- µ m or 0.001
degrees
1336 Plus cam position for safe cams 10000 2147000000 -- µ m or 0.001
degrees
1337 Minus cam position for safe
cams
-10000 -2147000000 -- µ m or 0.001
degrees
1340 Tolerance for safe cams 100 10000 -- µ m or 0.001
degrees
1342 Actual value comparison
tolerance (cross-check)
100 10000 or
360000
-- µ m or 0.001
degrees
1344 Actual value comparison
tolerance (referencing)
10 1000 or
36000
-- µ m or 0.001
degrees
1350 Tolerance time for SGE
switchover
500 10000 -- ms
1351 Delay time speed switchover 100 10000 -- ms
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–85
SINUMERIK 840C (IA)
