Siemens SIMODRIVE 611-D Installation Guide

09.95 1 NC/Drive Machine Data
1.11.4 FDD/MSD specific diagnostics/service MD (as from SW 4)
1.11.4 FDD/MSD specific diagnostics/service MD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
10000-
10014
Drive configuration 0000 FFFF -- HEX
10100-
10114
Module order code 0 65535 -- --
10200-
10214
Power section code 0000 FFFF -- HEX
10900 Data version -- -- -- --
10901 Firmware version -- -- -- --
10902 Firmware date -- -- -- --
10903 Hardware configuration -- -- -- --
11000 Ramp-up phase -- 0505 -- --
11001 CRC error -- FFFF -- HEX
11002 Status word 1 -- FFFF -- HEX
11003 Status word 2 -- FFFF -- HEX
11004 Control word 1 -- FFFF -- HEX
11005 Control word 2 -- FFFF -- HEX
11006 Status class 2 -- FFFF -- HEX
11007 Status class 3 -- FFFF -- HEX
11008 Drive status -- 5 -- --
11009 Capacity utilization -- 7FFF -- HEX
11010 Torque setpoint value -- 32 767 -- --
11011 Active power -- 327.67 -- kW
11012 Current actual value -- 32 767 -- --
11013 Speed actual value -- 200 -- %
12000 Position actual value -- 99999999 -- --
12001 v - max (FDD)/n - set-max (MSD)
12002 Position controller frequency
12003 Actual gear stage
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–77
