1 NC/Drive Machine Data 09.95
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
2246 Hysteresis speed-dependent
torque setpoint smoothing
50.0 1 000.0 – rev/min
2400 Motor rated speed 1 500.0 25 000.0 – rev/min
2401 Speed for maximum motor
operational speed
1 500.0 50 000.0 – rev/min
2403 Creep speed pulse
suppression
0.0/2.0 7 200.0 – rev/min
2405 Monitoring speed motor 0.0 110.0 – %
2407 P gain speed controller 0.0 100 000.0 – Nm/s
-1
2408 P gain upper adaptation speed 1.0 100 000.0 – Nm/s
-1
2409 Reset time speed controller 0.0 500.0 – ms
2410 Reset time upper adaptation
speed
10.0 500.0 – ms
2411 Lower adaptation speed 0.0 50 000.0 – rev/min
2412 Upper adaptation speed 0.0 50 000.0 – rev/min
2413 Select adaptation speed
controller
0 1 – –
2417 n
x
for n
act
< n
x
message 6 000.0 50 000.0 – rev/min
2418 n
min
for n
act
< n
min
message 5.0 25 000.0 – rev/min
2426 Tolerance band for n
set
= n
act
message
20.0 10 000.0 – rev/min
2451 P gain speed controller AM
2)
0.3 1 000.0 -- Nm/s
-1
2453 Integral-action time speed
controller AM
2)
140.0 500.0 -- ms
2458 Current setpoint val. contr.
operation AM
2)
90.0 150.0 -- %
2459 Torque smoothing time
constant AM
2)
4.0 100.0 -- ms
2465 Switchover speed MSD/AM
operation
2)
50 000.0 50 000.0 -- rev/min
2602 Motor temperature warning
threshold
120 200 – °C
2607 Switchoff limit motor
temperature
155 200 – °C
2608 Fixed temperature 0 200 – °C
2711 Significance speed
representation
0.0 100 000.0 – rev/min
2712 Significance rotor flux
representation
0.0 100 000.0 – µVs
2713 Significance torque
representation
0.0 100 000.0 – µNm
2714 Significance shaft position
representation
2)
- 1 000 000 -- Degrees
2725 Scaling torque setpoint
interface
0.0 100 000.0 – Nm
_______
1) SW 4 and higher
2) SW 5 and higher
1–76 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
