07.97 1 NC/Drive Machine Data
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1798 Firmware date 0 32 767 – –
1799 Firmware version 0 32 767 – –
2005 No. of encoder marks motor
measuring system
2 048 8 192 – Incr/rev
2102 Motor code number 0 65 535 – –
2103 Rated motor current 0.0 500.0 – A
2117 Motor moment of inertia 0.0 32.0 – kgm
2
2120 P gain current controller 10.0 10 000.0 – V/A
2121 Reset time current controller 2 000.0 8 000.0 – µs
2130 Rated motor power 0.0 1 500.0 – kW
2132 Rated motor voltage 0.0 5 000.0 – V
2134 Rated motor frequency 0.0 3 000.0 – Hz
2135 Motor no-load voltage 0.0 500.0 – V
2136 Motor no-load current 0.0 500.0 – A
2137 Stator resistance cold 0.0 20.0 –
2138 Rotor resistance cold 0.0 20.0 –
2139 Stator leakage reactance 0.0 100.0 –
2140 Rotor leakage reactance 0.0 100.0 –
2141 Magnetizing reactance 0.0 1 000.0 –
2142 Speed at start of field
weakening
0.0 50 000.0 – rev/min
2143 Upper speed L
h
characteristic 0.0 50 000.0 – rev/min
2144 Gain factor L
h
characteristic 100.0 500.0 – %
2145 Breakdown torque reduction
factor
100.0 1 000.0 – %
2146 Maximum motor speed 0.0 50 000.0 – rev/min
2147 Speed limitation 7 000.0/
8 000.0
50 000.0 – rev/min
2150 P gain flux controller 400.0 100 000.0 – A/Vs
2151 Reset time flux controller 10.0 500.0 – ms
2230 1st torque limiting value 100.0 900.0 – %
2231 2nd torque limiting value 100.0 100.0 – %
2232 Switching speed from MD 2230
to MD 2231
6 000.0 50 000.0 – rev/min
2233 Generative limitation 100.0 100.0 – %
2234 Hysteresis MD 1232 50.0 1 000.0 – rev/min
2235 1st power limit value 100.0 900.0 – %
2236 2nd power limit value 100.0 100.0 – %
2238 Current limit 150.0 300.0 – %
2239 Torque limit setup operation 1.0 100.0 – %
2245 Threshold speed-dependent
torque setpoint smoothing
0.0 50 000.0 – rev/min
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–75
SINUMERIK 840C (IA)
