4 NC Setting Data 01.99
4.2 NC setting data bits
4.2 NC setting data bits
7 6 5 4 3 2 1 0
Bit No.
SD No.
5000
Calculation of
overtravel
compensation
L900 w/o
safety
clearance to
drill axis
Cycles L97
L99 with G620
active
Turning
cycles
2)
Drill. and
mill. patterns
2)
Drilling
cyles
2)
5001
Aut. save of
part programs
on harddisk
Display actual
value system
for workpiece
5004
Var. incr.
with DRF
540*
Do not load
workpiece
with POWER
ON (from
SW 5.7)
Axis
converter
on/off
560
* 1)
Scale factor
effective at
machine
Rapid
override not
active
Feed override
not active
Setting data handwheel weighting
7 6 5 4 3 2 1 0
Bit No.
SD No.
564*
(SW3 and
higher)
10000 1000 100 10 1
Increments per handwheel pulse
Setting data spindle converter
7 6 5 4 3 2 1 0
Bit No.
SD No.
600* to
625*
(SW2 and
higher)
Spindle converter
Setting data axis converter
7 6 5 4 3 2 1 0
Bit No.
SD No.
626* to
699*
(SW2 and
higher)
Axis converter
Setting data software cams
7 6 5 4 3 2 1 0
Bit No.
SD No.
7000
to
7007
Software cams
_______
1) Axis-specific value, *= 0 axis 1 to 29 axis 30
2) Function extension of UMS 03 can be used
4–2 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
