1 NC/Drive Machine Data 07.97
1.11 611A drive machine data
1.11 611A drive machine data
1.11.1 611A drive machine data MSD (SW 3)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1 Speed setpoint 0 -- -- rev/min
2 Speed actual value 0 -- -- rev/min
3 Motor voltage -- -- -- V
4 Capacity utilization -- -- -- %
6 DC link voltage -- -- -- V
7 Motor current -- -- -- A
8 Motor reactive power -- -- -- KVA
9 Motor apparent power -- -- -- KW
10 Motor temperature -- -- -- °C
11 Status of binary inputs -- -- -- HEX
14 Speed for max. motor
operational speed Motor 1
Motor max.
speed
-- -- rev/min
19 Rounding degree speed
setpoint
0 30 -- --
20 Diagnosis speed actual value 0000 -- -- HEX
21 n
min
for n
act
< n
min
message
Motor 1
12 Rated speed -- rev/min
22 Creep speed
pulse suppression
Rated speed
256
Rated speed
-- rev/min
23 n
x
for n
act
<n
x
message
Motor 1
6000 Motor max.
speed
-- rev/min
27 Tolerance band for n
set
= n
act
Motor 1
20 Rated speed
-1
16
-- rev/min
28 Diagnosis 0000 -- -- HEX
29 Speed limitation Motor 1 Motor max.
speed
Motor max.
speed
-- rev/min
1–52 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
