09.01 1 NC/Drive Machine Data
1.12.3 SI service data
1.12.3 SI service data
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
300 Actual value safety functions
NC
-- -- -- µ m/min or
0.001 rev/min
301 Diagnosis for STOP F -- -- -- --
302 Actual value safety functions
drive
-- -- -- µ m/min or
0.001 rev/min
303 SI ramp-up position axis
(from SW 6)
-- -- -- --
304 SI ramp-up position drive
(from SW 6)
-- -- -- --
305 SGE image axis (from SW 6) -- -- -- --
306 SGE image drive (from SW 6) -- -- -- --
307 SGA image axis (from SW 6) -- -- -- --
308 SGA image drive (from SW 6) -- -- -- --
309 SI speed difference 0----mm/min or
rev/min
310 Maximum SI speed difference 0----mm/min or
rev/min
1000 Parameterization error safety
functions
-- -- -- --
1001 SGE status in NCK monitoring
channel
-- -- --
1002 SGE status in drive monitoring
channel
-- -- -- --
1003 SGA status in NCK monitoring
channel
-- -- -- --
1004 SGA status in drive monitoring
channel
-- -- -- --
1005 SGE image 2 axis (from SW 6) -- -- -- --
1006 SGE image 2 drive (from SW 6) -- -- -- --
1007 SGA image 2 axis (from SW 6) -- -- -- --
1008 SGA image 2 drive (from SW 6) -- -- -- --
