1 NC/Drive Machine Data 09.01
1.12.2 SI drive machine data
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1352 Transition time STOP C to safe
operational stop
100 10000 -- ms
1353 Transition time STOP D to safe
operational stop
100 10000 -- ms
1354 Transition time STOP E to safe
operational stop
100 10000 -- ms
1356 Delay time pulse disable 100 10000 -- ms
1357 Time for testing pulse disable 100 10000 -- ms
1360 Creep speed
Pulse disabling
0.0 1000.0 -- rev/min or
mm/min
1361 Stop response safe speed 2 4 -- --
1362 Stop response safe limit
position
2 4 -- --
1390 Safety Integrated Firmware
version
-- -- -- --
1391 Diagnosis: NC results list 1 0 FFFFFFFF -- --
1392 Diagnosis: 611D result list 1 0 FFFFFFFF -- --
1393 Diagnosis: NC result list 2 0 FFFFFFFF -- --
1394 Diagnosis: 611D result list 2 0 FFFFFFFF -- --
1395 Diagnosis for STOP F 32767 32767 -- --
1396 User acknowledgement 0000 FFFF -- HEX
1397 611D internal acknowledgement 0000 FFFF -- HEX
1398 Display checksum of MD for
safety functions
00000000 FFFFFFFF -- --
1399 Checksum of MD for safety
functions
00000000 FFFFFFFF -- --
1–86 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
