1 NC/Drive Machine Data 07.97
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1665 Operating time factor IPO/
NREG cycle for RFG
2)
2.0 20.0 – –
1700 Status of binary inputs 0000 7FFF – Hex
1701 DC link voltage 0 32 767 – V
1702 Motor temperature 0 32 767 – °C
1703 Lead time conversion motor
measuring system
1)
0 32 767 – µs
1704 Lead time conversion direct
measuring system
1)
0 32 767 – µs
1705 Voltage setpoint value
(effective) (from SW 6)
V
eff
(chained)
1706 Set speed 0.0 1 000 000 – rev/min
1707 Speed actual value 0.0 1 000 000 – rev/min
1708 Smoothed current actual value 0.0 1 000 000 – %
1709 Significance voltage
representation
2)
0.0 1 000 000 – –
1710 Significance current
representation
2)
0.0 1 000 000 – µA
1711 Significance speed
representation
2)
0.0 1 000 000 – rev/min
1712 Significance rotor flux
representation
2)
0.0 1 000 000 – µVs
1713 Significance torque
representation
2)
0.0 1 000 000 – µNm
1714 Significance shaft position
representation
4)
- 1 000 000 -- Degrees
1719 Current actual value
(effective) (from SW 6)
A
eff
1720 CRC diagnosis parameter 0000 FFFF – Hex
1721 Diagnosis speed actual value 0000 FFFF – Hex
1722 Capacity utilization 0 1 000 000 – ‰
1723 Diagnostics ramp-up time
2)
0 60 000 – ms
1724 Diagnostics concentricity
monitoring
2)
0 60 000 – –
1725 Scaling torque setpoint
interface
2)
0.0 1 000 000 – Nm
1730 Operating mode
4)
, display 0000 FFFF -- Hex
1731 Image ZK1 PO register 0000 FFFF – Hex
1732 Image ZK1 RES register 0000 FFFF – Hex
1733 NPFK diagnosis counter 0 32 767 – –
1790 Measuring circuit type indirect
measuring system
0 32 767 – –
1791 Measuring circuit type direct
measuring system
0 32 767 – –
1797 Data version 0 32 767 – –
_______
1) Up to SW 4
2) SW 4 and higher
3) SW 4 only
4) SW 5 and higher
1–74 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
