Siemens SIMODRIVE 611-D Installation Guide

07.97 1 NC/Drive Machine Data
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1623 Threshold variable message
function
000000 FFFFFF – Hex
1624 Hysteresis variable message
function
000000 FFFFFF – Hex
1625 Pickup delay variable message
function
0 10 000 – ms
1626 Delayed dropout variable
message function
0 10 000 – ms
1630 Response threshold ZWK
monitoring only
550 600 – V
1631 Response voltage generator
axis
450 570 – V
1632 Voltage step for generator
control
30 300 – V
1633 Cutout threshold for generative
mode
510 580 – V
1634 Response threshold
emergency retraction
400 580 – V
1635 Minimum speed generator axis 0.0 50 000.0 – rev/min
1636 Drive modes
Emergency retraction
3)
1637 Delay time regen. braking
3)
1638 Emergency retraction time
3)
1639 Emergency retraction speed
3)
1650 Diagnosis control 0000 FFFF – Hex
1651 Sign. number min/max memory 0 100 – –
1652 Memory location min/max
memory
0000 FFFF – Hex
1653 Minimum value min/max
memory
0000 0000 FFFF FFFF – Hex
1654 Maximum value min/max
memory
0000 0000 FFFF FFFF – Hex
1655 Segment memory location
monitor
0 1 – –
1656 Add. memory location monitor 0000 FFFF – Hex
1657 Value display monitor
0000 0000 FFFF FFFF – Hex
1658 Value input monitor
1)
0000 0000 FFFF FFFF – Hex
1659 Value acceptance monitor
1)
0 1 – –
1660 Motor frequency V/f operat.
2)
0.0 10000.0 – Hz
1661 V/f ratio in V/f operation
2)
2.4 100.0 – V/Hz
1662 Change motor frequency
V/f operation
2)
5.0 10 000.0 – Hz/s
_______
1) Up to SW 4
2) SW 4 only
3) These machine data are relevant only for Siemens-internal purposes and must not be changed.
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–73
SINUMERIK 840C (IA)
