1 NC/Drive Machine Data 09.95
1.11.3 611D drive machine data FDD/MSD (as from SW 4)
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
1515 Bandwidth speed setp. filter 1 500.0 7 999.0 – Hz
1516 Bandwidth counter speed
setpoint filter 1
0.0 7 999.0 – Hz
1517 Stop frequency speed setpoint
filter 2
3 500.0 7 999.0 – Hz
1518 Bandwidth
speed setp. filter 2 500.0 7 999.0 – Hz
1519 Bandwidth counter speed
setpoint filter 2
0.0 7 999.0 – Hz
1520 Band stop nat. freq. speed
setp. frequency 1 (from SW 5)
100 141 -- %
1521 Band stop nat. freq. speed
setp. frequency 2 (from SW 5)
100 141 -- %
1600 Concealab. alarms (Power On) 0000 FFFF – Hex
1601 Concealable alarms (Reset) 0000 FFFF – Hex
1602 Motor temperature warning
threshold
120 200 – °C
1603 Timer motor temperature alarm 240 600 – s
1604 DC link undervoltage warning
threshold
200 600 – V
1605 Timer controller against stop 200.0 10 000.0 – ms
1606 Threshold controller against
stop
8 000.0/
30.0
50 000.0 – rev/min
1607 Motor temperature cut-off limit 155 200 – °C
1608 Fixed temperature 0 200 – °C
1610 Diagnosis functions 0000/
0001
0001 – Hex
1611 Response threshold dn/dt 800 1 600 – %
1612 Configured shutdown reaction
PO alarms
0D3C/
FFFF
FFFF – Hex
1613 Configured shutdown reaction
reset alarms
0100/
FFFF
FFFF – Hex
1615 Tolerance concentricity monit. 20 100.0 – rev/min
1620 Bits variable message function 0000 FFFF – Hex
1621 Signal number variable
message function
0 100 – –
1622 Add. variable message function 0000 FFFF – Hex
1–72 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
