1 NC/Drive Machine Data 07.97
1.12.1 SI NC machine data
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
4700* Output assignment SN1+ 0 30200161 -- Decimal
4704* Output assignment SN1-
0 30200161 -- Decimal
4708* Output assignment SN2+
0 30200161 -- Decimal
4712* Output assignment SN2-
0 30200161 -- Decimal
4716* Output assignment SN3+
0 30200161 -- Decimal
4720* Output assignment SN3-
0 30200161 -- Decimal
4724* Output assignment SN4+
0 30200161 -- Decimal
4728* Output assignment SN4-
0 30200161 -- Decimal
4732* Output assignment SBH/SG
active
0 30200161 -- Decimal
4736* Output assignment Axis safely
referenced
0 30200161 -- Decimal
4740* Output assignment Enable
pulses
0 30200161 -- Decimal
4744* Output assignment for SBH
active (from SW 6)
0 30200161 -- Decimal
4752* Output assignment for SG
active bit 0 (from SW 6)
0 30200161 -- Decimal
4756* Output assignment for SG
active bit 1 (from SW 6)
0 30200161 -- Decimal
4760* Output assignment for n<nx
0 30200161 -- Decimal
4772* Output assignment for SG1
active (from SW 6)
0 30200161 -- Decimal
4776* Output assignment for SG2
active (from SW 6)
0 30200161 -- Decimal
4780* Output assignment for SG3
active (from SW 6)
0 30200161 -- Decimal
4784* Output assignment for SG4
active (from SW 6)
0 30200161 -- Decimal
1–84 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
SINUMERIK 840C (IA)
