Siemens SIMODRIVE 611-D Installation Guide

04.96 1 NC/Drive Machine Data
1.12.1 SI NC machine data
Activation of NKC I/O for SI
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
45800 SGE mask CSB (low) 0 11111111 -- Binary
45802 SGE mask mixed I/O 1 (low) 0 11111111
-- Binary
45803 SGE mask mixed I/O 1 (high) 0 11111111
-- Binary
45804 SGE mask mixed I/O 2 (low) 0 11111111
-- Binary
45805 SGE mask mixed I/O 2 (high) 0 11111111
-- Binary
45808 SGA mask mixed I/O 1 (low) 0 11111111
-- Binary
45809 SGA mask mixed I/O 1 (high) 0 11111111
-- Binary
45810 SGA mask mixed I/O 2 (low) 0 11111111
-- Binary
45811 SGA mask mixed I/O 2 (high) 0 11111111
-- Binary
Input/output assignment
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
4600* Input assignment SBH/SG
deselection
0 30200161 -- Decimal
4604* Input assignment SBH
deselection
0 30200161 -- Decimal
4608* Input assignment "Pulses
disabled" status
0 30200161 -- Decimal
4612* Input assignment SG selection,
bit 0
0 30200161 -- Decimal
4616* Input assignment SG selection,
bit 1
0 30200161 -- Decimal
4632* Input assignment
gear ratio selection, bit 0
0 30200161 -- Decimal
4636* Input assignment
gear ratio selection, bit 1
0 30200161 -- Decimal
4640* Input assignment
gear ratio selection, bit 2
0 30200161 -- Decimal
4648* Input assignment SE selection
0 30200161 -- Decimal
4660* Input assignment Test stop
selection
0 30200161 -- Decimal
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–83
SINUMERIK 840C (IA)
