Siemens SIMODRIVE 611-D Installation Guide

07.97 1 NC/Drive Machine Data
1.10.1 Spindle-specific MD
D e s i g n a t i o n
MD
No.
Standard
value
Maximum input
value
Reference
system
Input
unit
2464*
.
.
.
2470*
Time const., setpoint filter
1)
2nd to 8th para. set
55
1000
16 000
2)
-- 0.1 ms
2471*
.
.
.
2478*
Speed limit 1st para. set
accel. adapt.
1)
:
8th para. set
99999 99999 --
rev/min or
0.1 rev/min
2479*
.
.
.
2486*
Acc. adapt. 1st para. set
factor
1) :
8th para. set
1000 10000 0.1 %
2487*
.
.
.
2493*
Position limit for M19
2nd to 8th para. set
1)
2000
720000
99 999 999
2)
MS units
2494*
.
.
.
2500*
P component comp. contr.
2nd to 8th para. set
1)
0 16000 -- 1
2501*
.
.
.
2507*
I component comp. contr.
2nd to 8th para. set
1)
0 16000 -- 1
2508*
.
.
.
2514*
D component comp. contr.
2nd to 8th para. set
1)
0 16000 -- 1
2515*
.
.
.
2521*
Time constant, parallel model
2nd to 8th para. set
1)
6000 16000 -- 0.01 ms
2522*
.
.
.
2529*
Alarm limit, 1st para. set
speed
1)
:
8th para. set
MD 403*
+10%
1)
99999 --
rev/min or
0.1 rev/min
2530*
.
.
.
2537*
Alarm limit, 1st para. set
acc. time const.
1)
:
8th para. set
MD 478*
-10%
1)
50000 -- ms
2546*
.
.
.
2552*
Tol. band synchr. fine
2nd to 8th para. set
1)
40
16000
99999999
3)
MS 1 units
2553*
.
.
.
2559*
Tol. band synchr. coarse
2nd to 8th para. set
1)
100
16000
99999999
3)
MS 1 units
_______
1) SW 4 and higher
2) SW 4.4 and higher
3) SW 5 and higher
© Siemens AG 1992 All Rights Reserved 6FC5197- AA60 1–45
SINUMERIK 840C (IA)
