1 NC/Drive Machine Data 01.99
1.5.1 General bits, standard assignments
M version T version
MD No. 7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0
5130
5131
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
5132
to
5139
1 1 1 1 1 1 1 1
:
1 1 1 1 1 1 1 1
1 1 1 1 1 1 1 1
:
1 1 1 1 1 1 1 1
5140 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5141 0 0 0 0 1 0 0 0 0 0 0 0 1 0 0 0
5142 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5143 0 0 0 0 0 1 1 0 0 0 0 0 0 1 1 0
5144 0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 1
5145 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5146 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5147 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5148 0 1 0 0 0 1 1 0 0 1 0 0 0 1 1 0
5149 0 1 0 0 1 1 0 0 0 1 0 0 1 1 0 0
5150 0 1 0 1 0 0 1 0 0 1 0 1 0 0 1 0
5151 0 1 0 1 1 1 1 1 0 1 0 1 1 1 1 1
5152 0 0 0 1 0 0 0 1 0 0 0 1 0 0 0 1
5153
to
5158
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5159
to
5182
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5183
to
5196
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0
:
0 0 0 0 0 0 0 0
5197 0 0 0 0 0 0 0 1
1)
0 0 0 0 0 0 0 0
1)
5198 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
5199 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
_______
1) Activated in overall reset mode
1–26 © Siemens AG 1992 All Rights Reserved 6FC5197- AA60
