5)
Only
available for SIMOTION D455-2 DP/PN in the TIA Portal (SCOUT TIA as of V4.5) Additional cycle clock setting: 125
µs
6)
Note the rules for the cycle clock ratio "PROFIBUS bus cycle clock" to "PROFINET cycle clock" when using two servos.
See also SINAMICS manuals.
Note
The DCC tasks T1...T3 are always assigned to Servo, IPO, or IPO_2.
You can also display the basic cycle clock used in HW Config. You can also activate the
Servo_fast/IPO_fast there, when required.
Parameter assignment / addressing
6.5 Configuring PROFINET IO
SIMOTION D4x5-2
150 Commissioning and Hardware Installation Manual, 03/2018, A5E33441636B
