Siemens SIMOTION D45 Series - Table 2-1 Mode Selector Position; Table 2-2 Mode Selector Settings

Operator control (hardware)
2.2 Operator control elements
D4x5
Manual, 03/2007 Edition
27
Switch positions
The following table contains the possible mode selector positions and the associated LED
displays. The mode selector positions are explained in the order in which they are arranged
on the SIMOTION D4x5.
Table 2-1 Mode selector position
Selector position Meaning LED
0 RUN RUN
1 STOPU SU/PF
2 STOP STOP
3 MRES
Other selector positions are not assigned
The following table contains the states of the SIMOTION D4x5 that can be set via the mode
selector.
Table 2-2 Mode selector settings
Meaning Explanations
RUN SIMOTION D4x5 is processing the user program and the associated system
performance:
• Reading process image of inputs
• Processing user programs assigned to the execution system.
• Writing process image of outputs
The technology packages are active in this state. They can execute commands from
the user program.
STOPU SIMOTION D4x5 is not processing a user program.
• The technology packages are active. Test and commissioning functions can be
executed. The user program is not active.
STOP SIMOTION D4x5 is not processing a user program.
• It is possible to load a complete user program.
• All system services (communications, etc.) are active.
• The I/O modules are in safe mode.
• The technology packages are inactive, i.e., all enables are deleted. No axis
motions can be executed.
MRES
(overall reset)
Switch setting for overall reset of the module.
The MRES position can be used to perform an overall reset on the SIMOTION D4x5,
thus restoring the factory settings.
See the
SIMOTION D4x5 Commissioning Manual, /1/.
