3.4 PROFINET IO interface (only for SIMOTION D4x5-2 DP/PN)
SIMOTION D4x5-2
56 Manual, 02/2012
Additional references
Detailed information on the states of the status LEDs can be found in the
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, Section
Diagnostics
.
Interface characteristics
Table 3- 7 Ports X150 P1 to P3
Characteristic Type
Connector type RJ45plus socket
Cable type PROFINET
Maximum cable length 100 m
Minimum transmission cycle 0.25 ms
Autocrossing Yes
i.e. both crossed and uncrossed cables can be used
Dust protection blanking plugs for sealing unused
PROFINET ports
Five blanking plugs contained in the D4x5-2 scope of delivery
Blanking plugs (50 pcs) order number: 6SL3066-4CA00-0AA0
Interface assignment
Table 3- 8 Assignment of the ports X150 P1 to P3
Representation Pin Name Description
1 TXP Transmit data +
2 TXN Transmit data -
3 RXP Receive data +
4 - Reserved, do not use
5 - Reserved, do not use
6 RXN Receive data -
7 - Reserved, do not use
8 - Reserved, do not use
Connectable devices
The following devices can be connected to the PROFINET IO interface:
● PG/PC programming devices (communication with SIMOTION SCOUT / STEP 7)
● SIMATIC HMI devices
● SIMATIC controllers with PROFINET interface
● Distributed I/O
● Drive units with PROFINET IO interface (standard devices)
