6.6 Terminal module TM41
Features of the TM41
With the TM41 Terminal Module, the number of available digital inputs/digital outputs and the
number of analog inputs within a drive system can be expanded. In addition, the TTL output
can be used for encoder simulation. The TM41 is connected by means of DRIVE-CLiQ.
The TB41 contains the following terminals:
Table 6-3 TM41 interface overview
Type Quantity
Digital inputs 4
Digital inputs/digital outputs 4
Analog inputs 1
TTL encoder output 1
Caution
The 50 mm clearances above and below the component must be observed.
Additional references
You will find detailed information about the TM41 Terminal Module in the
Supplemental
SINAMICS System Components for SIMOTION
Manual.
