Interfaces
3.2 DRIVE-CLiQ interfaces
SIMOTION D4x5-2
50 Manual, 02/2012
Characteristics
Table 3- 3 DRIVE-CLiQ interface X100 - X105 (D425-2: Only X100 - X103)
Characteristic Type
Connector type DRIVE-CLiQ connector (RJ45 socket)
Cable type DRIVE-CLiQ standard (inside the control cabinet)
Cable type MOTION CONNECT (outside the control cabinet)
Max. cable length 100 m
Dust protection blanking plugs for sealing
unused DRIVE-CLiQ ports
Five blanking plugs contained in the D4x5-2 scope of
delivery
Blanking plugs (50 pcs) order number:
6SL3066-4CA00-0AA0
DRIVE-CLiQ pin assignment
Table 3- 4 DRIVE-CLiQ interface X100 - X105 (D425-2: Only X100 - X103)
PIN Signal name Signal type Meaning
1 TXP O Transmit data +
2 TXN O Transmit data -
3 RXP I Receive data +
4 ---- ---- Reserved, do not use
5 ---- ---- Reserved, do not use
6 RXN I Receive data -
7 ---- ---- Reserved, do not use
8 ---- ---- Reserved, do not use
A + (24 V) VO Power supply for DRIVE-CLiQ, 450 mA maximum
B M (0 V) VO Ground to 24 V
Signal type: I = Input; O = Output; VO = Voltage Output
Additional references
● SINAMICS S120 Control Units and Additional System Components Manual
●
SINAMICS S120 Booksize Power Units Manual
●
SINAMICS S120 for AC Drives Manual
●
SINAMICS S120 Commissioning Manual
●
Terminal Modules TM15 and TM17 High Feature Commissioning Manual
●
TM15/TM17 High Feature Manual
● For order numbers, refer to the list of references (separate document)
