Interfaces
3.3 Ethernet interfaces
SIMOTION D4x5-2
54 Manual, 02/2012
Interface characteristics
Table 3- 5 X127 P1 and X130 P1 (X120 P1 only for SIMOTION D4x5-2 DP)
Characteristic Type
Connector type RJ45 socket connector
Cable type Industrial Ethernet cable
• 4- and 8-wire cables can be used for 10/100 Mbit/s
• 8-wire cables must be used for 1000 Mbit/s
Max. cable length 100 m
Autocrossing Yes
Dust protection blanking plugs for
sealing unused Ethernet ports
Five blanking plugs contained in the D4x5-2 scope of delivery
Blanking plugs (50 pcs) order number: 6SL3 066-4CA00-0AA0
Miscellaneous X127 P1, X120 P1 and X130 P1 are full-duplex 10/100/1000 Mbit/s Ethernet ports
Pin assignment
Table 3- 6 X127 P1 and X130 P1 Ethernet interfaces (X120 P1 only for SIMOTION D4x5-2 DP)
Assignment in 10/100 Mbit mode Assignment in 1 Gbit mode
Representation Pin
Signal
name
1)
Signal type Meaning Signal
name
1)
Signal type Meaning
1 TXP O Ethernet transmit
differential signal
DA+ B Bidirectional pair A+
2 TXN O Ethernet transmit
differential signal
DA- B Bidirectional pair A-
3 RXP I Ethernet receive
differential signal
DB+ B Bidirectional pair B+
4 - - - - - - Reserved, do not use DC+ B Bidirectional pair C+
5 - - - - - - Reserved, do not use DC B Bidirectional pair C-
6 RXN I Ethernet receive
differential signal
DB- B Bidirectional pair B-
7 - - - - - - Reserved, do not use DD+ B Bidirectional pair D+
8 - - - - - - Reserved, do not use DD- B Bidirectional pair D-
I = Input; O = Output; B = Bidirectional
1)
Autocrossing functionality (if required, transmit and receive lines switch over)
Note
The MAC addresses are imprinted on an adhesive label that is located behind the protective
cover and can be seen from the front.
