Technical data of the D4x5-2
4.2 Mechanical and climatic ambient conditions
SIMOTION D4x5-2
76 Manual, 02/2012
Ambient conditions for operation
SIMOTION D4x5-2 may be used under the following ambient conditions:
Table 4- 2 Environmental requirements
Ambient conditions Application range Comments
Climatic ambient conditions
Climate class 3K3 According to EN 60721-3
Permissible ambient
temperature:
During operation when
installed vertically
From 0° C to +55° C,
up to 2000 m above sea
level
As of an altitude of 2000 m, the max. ambient temperature
decreases by 7°C every 1000 m increase in altitude.
The maximum supply air temperature for all modules is 55° C.
The fan/battery module is always required for SIMOTION D4x5-
2 Control Units.
Relative humidity From 5% to 95%
Condensation, icing, drip,
spray and splash water
Not permissible
Installation altitude Max. 4000 m above sea
level
For SINAMICS S120 drive components, see SINAMICS
Manuals.
Atmospheric pressure 620 hPa to 1060 hPa Corresponding height 4000 m - 0 m above mean sea level
Biological, chemical and mechanical influences, pollutants
Biological environmental conditions
• Class 3B1 according to EN 60 721-3-3;
Mold, mold growth, slime, rodents, termite and other animal
vermin are not permissible.
Chemically active environmental conditions
• Class 3C1 according to EN 60721-3-3
Mechanically active environmental conditions
• Class 3S1 according to EN 60721-3-3, conductive dust not
permitted
Other data
Table 4- 3 Other data
Data
Degree of protection according to EN 60529
(IEC 60529)
IP 20
Pollution degree 2 according to EN 60 664-1
