1.1 TM15 and TM17 High Feature modules - Introduction
TM15 / TM17 High Feature Operating Manual
12 Commissioning Manual, 05/2009
Structure
The modules are mounted on a DIN rail in accordance with DIN EN 50 022 (35 x 15 / 7.5).
They are connected to the SIMOTION/SINAMICS hardware via DRIVE CLiQ.
Several TM1x modules can be installed on one DRIVE CLiQ line.
The SINAMICS S120 Manuals provide more information on the system structure of
SINAMICS S and associated hardware.
Note
In the "Supplemental SINAMICS System Components for SIMOTION" Manual, you will find
information about the design of Terminal Modules TM15 and TM17 High Feature as well as
a description of the interfaces and installation.
See also
Maximum number of terminal modules (Page 40)
