Siemens SIMOTION TM15 Commissioning Manual

TM15 / TM17 High Feature Operating Manual
Commissioning Manual, 05/2009
69
Technical data
6
6.1 Operating modes
6.1.1 Overview of operating modes
Each channel can be individually configured for one of the following modes:
Table 6- 1 Operating modes
Mode of operation TM15 TM17 High Feature
Digital input (DI) X X
Input of measuring input
(single measurement)
X X
Input of measuring input
(cyclic measurement)
- X
Input of measuring input with level-
triggered enable
- X (channels 0 to 5)
Enabling signal - X (channels 10...15)
Digital output (DO) X X
Output of output cam X X
Output of output cam
with level-triggered enable
- X (channels 0 to 5)
Output of output cam
with edge-triggered enable
- X (channels 0 to 5)
