Configuration/programming
2.2 Configuring and programming TM1x modules
TM15 / TM17 High Feature Operating Manual
Commissioning Manual, 05/2009
31
2. Note that the addresses have been assigned automatically. These addresses are the
logical start addresses of the module in the message frame. You must later add the offset
values from the graphical configuration screen form to these addresses if you want to
determine the addresses for the individual I/O channels.
Note
When a TM1x is reconfigured, the structure of its message frame is changed, thus
necessitating a realignment with HW Config. This process will create new (modified)
addresses for the inputs and outputs. In addition, the I/O address assignment of the
technology object must be updated.
Even if the operating mode of a measuring input is changed (once/cyclically), realignment
with HW Config is required, although this does not generate any new (changed)
addresses for the inputs and outputs.
Note
Before making changes in the configuration screen forms of the TM15/TM17 High
Feature Terminal Modules, you must close the screen form for aligning the hardware (see
figure above).
