Siemens SIMOTION TM15 Commissioning Manual

Technical data
6.1 Operating modes
TM15 / TM17 High Feature Operating Manual
Commissioning Manual, 05/2009
71
Table 6- 2 Timing for input of measuring input
Timer TM15 TM17 High Feature Comments
T1 125 µs
1
1 µs Resolution
T2 ≥ 125 µs
1
≥ 1 µs/125 µs TM17: Depends on selected
filter times
T3 ≥ 125 µs
1
≥ 1 µs/125 µs TM17: Depends on selected
filter times
T4 Depends on ratio of IPO to servo
T5 Not applicable
(TM15 does not have an
enable function)
≥ 1 µs/125 µs TM17: Depends on selected
filter times
Times specified for positive logic.
IPO = Interpolator cycle clock
1
DRIVE CLiQ cycle clock, but at least 125 µs
See also
System behavior with binary inputs and outputs (Page 76)
System timing for single measurement (Page 78)
System behavior with cyclic measurement (Page 79)
Configuring I/O channels – TM17 High Feature (Page 25)
