Functions
6.4 Setpoint sources
SINAMICS G110D
Operating Instructions, 07/2016, FW V3.63, A5E36768472B AB
105
Selecting the setpoint source [P1000]
Selecting the setpoint source [P1000]
The speed of the motor can be set using the frequency setpoint. The following sources can
be used to specify the frequency setpoint:
● Analog inputs
● Fixed frequency using digital inputs (default setting)
● Motorized potentiometer
● Fieldbuses
Table 6- 16 Settings to select the possible frequency setpoint sources
Standard: Access to the most frequently used parameters
P1000 = … 0: No main setpoint
1: MOP setpoint / motorized potentiometer
2: Analog setpoint
3: Fixed frequency (default setting)
4: USS on RS 232
Adding setpoints from different sources
You can add several setpoints using frequency setpoint source P1000. For more information,
see the List Manual (P1000 in the parameter list and function diagram 5000).
