SINAMICS G110D
Operating Instructions, 07/2016, FW V3.63, A5E36768472B AB
209
Technical data
9
9.1
Technical data of the SINAMICS G110D
Technical data of the SINAMICS G110D
Feature
Data
Line operating voltage 3 AC 380 V … 500 V ± 10% The permissible line operating voltage
depends on the installation altitude
Operating voltage Supply from the ASi bus or an external 24 V DC supply (20.4 V to 28.8 V,
0.5 A)
Input frequency 47 Hz … 63 Hz
Power factor λ
0.7 ... 0.85
Overload capability
The SINAMICS G110D can either be operated with high overload (HO). In
order to avoid overtemperature of the Power Module, after the overload,
as a minimum its load must decrease back to the base load (HO base
load or LO base load).
HO base load
0.75 kW ... 7.5 kW
150% overload for 57 s
200% overload for 3 s
87% HO base load for 240 s
See note 1.
Digital inputs 4; PNP
Low < 5 V, High > 10 V, maximum input voltage 30 V, 5.5 mA
Analog inputs 1, with 10-bit resolution
AI0: 0 V to 10 V, unipolar voltage only
Analog input can also be configured as a digital input
Setpoint resolution
0.01 Hz
Pulse frequency
4 kHz for 0.75 kW ... 7.5 kW (HO)
Possible braking meth-
ods
DC braking, dynamic braking with integrated braking chopper
Degree of protection
IP65
Operating temperature 0.75 kW ... 7.5 kW (HO)
-10 °C … +40 °C (14 °F … 104 °F)
See note 1.
Higher operating temperatures are
possible when the rated power is
reduced (derating)
Transport/storage tem-
perature
-40 °C … +70 °C (-40 °F … 158 °F)
Relative humidity
< 95% RH - condensation not permissible
Installation altitude 0.75 kW ... 7.5 kW (HO)
Up to 1000 m (3300 ft) above sea level
Higher altitudes are possible
when the rated power is re-
duced (derating)
Dimensions (WxHxD) FSA: 195 mm x 425 mm 125 mm (145 mm with repair switch)
FSB: 195 mm x 425 mm 165 mm (165 mm with repair switch)
FSC: 195 mm x 425 mm 240 mm (240 mm with repair switch)
