Functions
6.11 Operation in fieldbus systems
SINAMICS G110D
Operating Instructions, 07/2016, FW V3.63, A5E36768472B AB
161
Drive ES Basic is the basic software of the engineering system, which combines the drive
technology and Siemens controllers. The STEP 7 Manager user interface acts as a basis
with which Drive ES Basic is used to integrate drives in the automation environment with
respect to communication, configuration and data storage.
Integrating the Inverter in a AS-i master
The CP343-2 module can be operated in the automation systems (AS or PLC) of the S7-300
series and in the ET200M system. It allows the connection of an AS-i chain to the
programmable controllers.
Image 6-24 Using the CP343-2 Master with the S7-300
