Connection
4.7 SINAMICS G110D Specifications
SINAMICS G110D
44 Operating Instructions, 07/2016, FW V3.63, A5E36768472B AB
The inverter is suitable for use on a circuit capable of delivering the short circuit current
shown in the tables below when protected by the branch circuit protection indicated.
Table 4- 5 Non-semiconductor fuses better than RK5 (JDDZ)
SINAMICS G110D model no.
Max current rating of fuse (A)
SINAMICS G110D SCCR with
fuse
6SL3511-.PE17-5AM.
10
100 kA, 480 V AC
6SL3511-.PE21-5AM. 15 100 kA, 480 V AC
6SL3511-.PE23-0AM.
25
100 kA, 480 V AC
6SL3511-.PE24-0AM. 30 100 kA, 480 V AC
6SL3511-.PE25-5AM.
30
100 kA, 480 V AC
6SL3511-.PE27-5AM.
30
100 kA, 480 V AC
Table 4- 6 Branch circuit protection with circuit breakers (DIVQ)
SINAMICS G110D model no.
Max current rating of circuit
breaker (A)
Circuit breaker types
SINAMICS G110D SCCR
with circuit breakers
6SL3511-.PE17-5AM. 15
3RV1742
65 kA, 480 V AC
3RV2711
65 kA, 480 Y / 277 V AC
LGG
65 kA, 480 V AC
CED6
65 kA, 480 V AC
6SL3511-.PE21-5AM. 15
3RV1742
65 kA, 480 V AC
3RV2711
65 kA, 480 Y / 277 V AC
LGG
65 kA, 480 V AC
CED6
65 kA, 480 V AC
6SL3511-.PE23-0AM. 25
3RV1742
65 kA, 480 V AC
3RV2721
50 kA, 480 Y / 277 V AC
LGG
65 kA, 480 V AC
CED6
65 kA, 480 V AC
6SL3511-.PE24-0AM. 35
3RV1742
65 kA, 480 V AC
3RV2721
50 kA, 480 Y / 277 V AC
LGG
65 kA, 480 V AC
CED6
65 kA, 480 V AC
6SL3511-.PE25-5AM. 45 65 kA, 480 V AC 65 kA, 480 V AC
50 kA, 480 Y / 277 V AC
50 kA, 480 Y / 277 V AC
65 kA, 480 V AC 65 kA, 480 V AC
65 kA, 480 V AC
65 kA, 480 V AC
6SL3511-.PE27-5AM. 60
65 kA, 480 V AC
65 kA, 480 V AC
50 kA, 480 Y / 277 V AC
50 kA, 480 Y / 277 V AC
65 kA, 480 V AC
65 kA, 480 V AC
65 kA, 480 V AC
65 kA, 480 V AC
