Diagnosis
Diagnostics using STARTER
6-216
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Note
r0786[1] indicates the normalization per volt.
A change in the output voltage by 1 volt corresponds to the value in this
parameter. The units are determined by the interconnected test signal.
Example:
r0786 = 1500.0 and the measuring signal is r0063 (CO: Actual speed smoothed)
A change of 1 volt at the output of the measuring socket corresponds to
1500.0 rpm.
Parameter overview (see List Manual)
Variable parameters
S p0771[0...2] CI: Test sockets signal source
S p0777[0...2] Test socket characteristic value x1
S P0778[0...2] Test socket characteristic value y1
S p0779[0...2] Test socket characteristic value x2
S p0780[0...2] Test socket characteristic value y2
S p0783[0...2] Test sockets offset
S p0784[0...2] Test socket limit on/off
Visualization parameters
S r0772[0...2] Test sockets output signal
S r0774[0...2] Test sockets output voltage
S r0786[0...2] Test socket normalization per volt
Function diagram overview (see List Manual)
S 8134 Test sockets
