Commissioning
Sequence of operations during commissioning
3-42
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
3.1 Sequence of operations during commissioning
Once the basic requirements have been met (see Chapter 2), you may proceed as
follows to commission the drive:
Table 3-1 Commissioning sequence
Step
Procedure Section/
Sub-
section
1 Create project with STARTER. 3.3
2 Configure the drive unit in STARTER. 3.4.4,
3.5.4,
3.6.4
3 Save the project in STARTER. 3.4.4,
3.5.4,
3.6.4
4 Go online with the target device in STARTER. 3.2.2
5 Load the project to the target system. 3.4.4,
3.5.4,
3.6.4
6 The motor starts rotating. 3.4.4,
3.5.4,
3.6.4
3.1.1 Safety guidelines
!
Danger
A hazardous voltage will be present in all components for a further 5 minutes after
the system has been shutdown.
Please follow the instructions on the component!
!
Caution
For safety reasons, Safety Integrated must be commissioned using STARTER in
online mode.
Reason:
STARTER should only be used to store the safety parameters of a project
monitoring channel. As a result, downloading a project with active Safety
Integrated results in safety problems (see Chapter 5).
