Messages – faults and alarms
6-224
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
External triggering of messages
If the appropriate binector input is interconnected with an input signal, fault 1, 2 or
3 or alarm 1, 2 or 3 can be triggered via an external input signal.
Once an external fault (1 to 3) has been triggered on the Control Unit drive object,
this fault is also present on all associated drive objects. If one of these external
faults is triggered on a different drive object, it is only present on that particular
drive object.
BI: p2106 --> External fault 1 --> F07860(A)
BI: p2107 --> External fault 2 --> F07861(A)
BI: p2108 --> External fault 3 --> F07862(A)
BI: p2112 --> External alarm 1 --> A07850(F)
BI: p2116 --> External alarm 2 --> A07851(F)
BI: p2117 --> External alarm 3 --> A07852(F)
Note
An external fault or warning is triggered by a 1/0 signal.
An external fault and alarm do not usually mean that an internal drive message
has been generated. The cause of an external fault and warning should, therefore,
be remedied outside the drive.
6.3.4 Parameters and function diagrams for faults and alarms
Parameter overview (see List Manual)
S r0944 Counter for fault buffer changes
...
S p0952 Fault counter
S p2100[0...19] Sets the fault number for fault response
...
S r2139 Status word faults/alarms
Function diagram overview (see List Manual)
S 1710 Outline diagram - monitoring, faults, warnings
S 8060 Faults and warnings - fault buffer
S 8065 Faults and warnings - warning buffer
S 8070 Faults and warnings - fault/warning trigger word r2129
S 8075 Faults and warnings - fault/warning configuration
