Basic Information about the Drive System
Data sets
7-233
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Copying a drive data set
Set parameter p0819 as follows:
1. p0819[0] = Number of the drive data set to be copied (source)
2. p0819[1] = Number of the drive data set to which the data is to be copied
(target)
3. p0819[2] = 1
Start copying.
Copying is finished when p0819[2] = 0.
Note
In STARTER, you can set the drive data sets via the drive configuration.
Function diagram overview (see List Manual)
S 8565 Drive Data Sets (DDS)
S 8570 Encoder Data Sets (EDS)
Parameter overview (see List Manual)
Variable parameters
S p0120 Power Module data set (PDS) number
S p0130 Motor data set (MDS) number
S p0140 Encoder data set (EDS) number
S p0170 Command data set (CDS) number
S p0180 Drive data set (DDS) number
S p0170 Copy command data set CDS
S p0810 BI: Command data set selection CDS bit 0
S p0811 BI: Command data set selection CDS bit 1
S p0812 BI: Command data set selection CDS bit 2
S p0813 BI: Command data set selection CDS bit 3
S p0819[0...2] Copy drive data set (DDS)
