Commissioning
Important STARTER functions
3-47
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Settings in STARTER for direct online connection via PROFIBUS
The following settings are required in STARTER for communication via PROFI-
BUS:
S Tools - PG/PC interface settings...
Add/remove interfaces
S Tools - PG/PC interface settings... - Properties
Activate/deactivate “PG/PC is only master on bus”
Note
S Baud rate
Switching STARTER to a working PROFIBUS:
STARTER automatically detects the baud rate used by SINAMICS for the
PROFIBUS.
Switching the STARTER for commissioning:
The Control Unit automatically detects the baud rate set in STARTER.
S PROFIBUS addresses
The PROFIBUS addresses for the individual drive units must be specified in
the project and must match the address settings on the devices.
