Siemens SINUMERIK 840D sl Manual

Connection of the Components
5.3 Line Modules Interfaces Description
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
5-23
5.3.3 Smart Line Modules (5 kW und 10 kW) with internal air cooling
5.3.3.1 Overview
3URWHFWLYHFRYHU
/('V
8QORFNLQJ
SURWHFWLYHFRYHU
3(FRQGXFWRU
FRQQHFWLRQ
01P
(OHFWURQLFSRZHU
VXSSO\
'&OLQN
EXVEDUV
;
SRZHUOLQHFRQQHFWLRQ
;
9WHUPLQDODGDSWHU
;;
WHUPLQDOV
Figure 5-11 Smart line module with internal air cooling (example 5 kW)

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
