Siemens SINUMERIK 840D sl - Shield Connection for Internal Heat Dissipation

Structure of the drive group
2.4 Shield Connection
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
2-21
2.4.3 Shield Connection for Internal Heat Dissipation
The two examples for preassembled cables on power components of different width follow:
Preassembled cable on a 100 mm
component
Preassembled cable on a 200 mm component
