Siemens SINUMERIK 840D sl - Operation of the Line Connection Components on the Supply Network

Connection of the Components
5.1 Power Supply Interface Variants
Guide for the SINUMERIK 840D sl machine configuring
5-2 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
5.1.2 Operation of the line connection components on the supply network
The SINAMICS S Booksize drive system is rated for direct operation on TN, TT, and IT line
supply systems with a rated voltage of 3-ph. 380 V to 3-ph. 480 V AC.
Note
Operation with a line filter is only permitted for a TN line supply.
QHW]BGLUDQVFKOYVG
/
/
3(
/
:98
'&3 '&1
)XVHV
/LQHUHDFWRUV
/LQH0RGXOH
/LQHFRQWDFWRU
RSWLRQDO
2WKHU
ORDGV
/LQHILOWHUV
RSWLRQDO
Figure 5-2 Direct operation on the line supply
