Connection of the Components
5.1 Power Supply Interface Variants
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
5-5
QHW]BWUHQQWUDIRYVG
/
/
3(
/
:9
8
'&3
'&1
1
)XVHV
/LQHUHDFWRUV
/LQH0RGXOH
)XVHV
,VRODWLQJ
WUDQVIRUPHU
/LQHFRQWDFWRU
RSWLRQDO
/LQHILOWHUV
RSWLRQDO
2WKHU
ORDGV
Figure 5-4 Isolating transformer
5.1.5 Line connection via a ground-fault circuit interrupter
In addition to protective measures against direct and indirect contact, selectively tripping
AC/DC-sensitive residual-current circuit-breakers (Type B) can be used.
Danger
Residual-current circuit-breakers alone are not permissible to provide protection against
direct and indirect contact.
