Page #134 background image
Connection of the Components
5.6 Electronics Power Supply
Guide for the SINUMERIK 840D sl machine configuring
5-50 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
Example for the splitting of the consumer lines:
NCU / NX
Line / Motor Modules
Supply of the Sensor Modules
Consumers such as relays, valves, etc.
Additional brakes not supplied from the Motor Module
Multiple power supplies are recommended for larger plant concepts.
Example of the separation:
Power supply for the direct drive system (NCU, NX, LM, MM, SME and SMC)
Power supply for additional consumers, such as brakes, valves and power contactors
If required, the circuit-breakers can be equipped with additional auxiliary switches. If these
signal contacts are fed to a higher-level controller, a detailed fault diagnosis can be
performed when the circuit-breakers trip.
Notes
SINAMICS components have a reverse polarity protection on the 24 VDC infeed side.
Line, Motor, Braking, Capacitor and Control Supply Modules are short-circuit resistant on
the 24 V busbar for a maximum current of 20 A. The 24 V terminal adapter for the infeed
has a maximum connection cross-section of 6 mm
2
.
If no higher short-circuit current can occur, a protection can be omitted. This means the
components can be connected directly to the power supply.
If higher short-circuit current occur, a protection against over-current / short-circuit must
be provided, max. 20 A, however. In a fault situation, the used power supply must be able
to supply the required current until tripping.
The maximum protection of the power supply infeed for Control Unit and Sensor Module
Cabinet depends on the connected cable cross-section (max. 2.5 mm
2
), maximum 20 A,
however.
The maximum protection of the controller inputs/outputs at the other components
depends on the connected cable cross-section:
Component max. cable cross-section
Control Unit 0.5 mm
2
Sensor Module Cabinet (SMC) 1.5 mm
2
Smart Line Module 1.5 mm
2
Active Line Module 1.5 mm
2
Motor Module 1.5 mm
2
Controller outputs at the Line, Motor and Braking Module, Control Unit and Sensor
Module Cabinet are short-circuit resistant.
