Structure of the drive group
2.4 Shield Connection
Guide for the SINUMERIK 840D sl machine configuring
2-14 Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
Figure 2-13 Dimension drawing of shield terminal plate on a 150 mm component (Line Module or
Motor Module) with internal air cooling
Note
A shield connecting plate can be ordered as option.
Recommended shield contacts: from Weidmüller, Order No. KLBÜ CO1 and KLBÜ CO4
Weidmüller: http://www.weidmueller.com
