Structure of the drive group
2.6 Heat Dissipation of the Control Cabinet
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
2-35
Electronic losses of Motor Modules/Line Modules
Table 2-6 Electronic losses of Motor Modules/Line Modules
Internal/external air cooling
Component
Power loss [W]
3A 20,4
5A 20,4
9A 20,4
18A 20,4
30A 21,6
45A 28,8
60A 28,8
85A 36,0
132A 36,0
Single Motor Modules
200 A 36,0
3 A 24,0
5 A 24,0
9 A 24,0
Double Motor Modules
18 A 24,0
16 kW 26,4
36 kW 36,0
55kW 45,6
80kW 36,0
Active Line Modules
120kW 60,0
5kW 24,0
10kW 31,2
16 kW 26,4
Smart Line Module
36 kW 36,0
