Siemens SINUMERIK 840D sl Manual

Connection of the Components
5.1 Power Supply Interface Variants
Guide for the SINUMERIK 840D sl machine configuring
Manual, 07/2006 Edition, 6FC5397-6CP10-0BA0
5-7
● The total length of the shielded power cables in the drive line-up (motor cables incl. line
supply cables from line filters to the connecting terminals of the line module) must be less
than 350 m.
● Only recommended line filters must be used during operation.
● Only one residual-current circuit-breaker may be connected in series (cascading is not
possible).
● Switching elements (main power switch, contactor) for connecting and disconnecting the
drive group have max. 35 ms delay time time between the closing/opening of the
individual main contacts.
Recommendation
SIEMENS selectively switching AC/DC-sensitive residual-current circuit-breaker in
accordance with EN 61800-5-1 of the 5SM series, e.g. 5SM36465 or 5SM36465+5SW3300
with auxiliary separation switch (1 break contact / 1 make contact) for 63 A rated current,
0.3 A rated residual current (see "BETA Installation Built-in Devices - ET B1" catalog).
Notice
AC or pulse-sensitive RCCBs are not suitable.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
