Siemens SINUMERIK 880 GA2 Programming Guide

05.91 2 Fundamentals of Programming
2.7 Input/output formats
%SEA
L
F
(SETTING DATA ACTIVE) (general setting data)
N...=...
L
F
N...=...
L
F
(0...9, 2000...2003,
Addresses with value assignments 3000...3171,
4000...4033,
5000...5771)
M02
L
F
(M30
L
F
) Setting data - End of data block
%SEA 1...16
L
F
Cycle setting data (channel-specific)
(SETTING DATA ACTIVE 4 )
N0
:
N99
System data
N400
:
N499
User data
N800
:
N849
System bits
N900
:
N949
User bits
M02
L
F
(M30
L
F
) Cycle setting data End of data block
%UMS
L
F
User memory submodule
:Hexcode Configured data
:Hexcode Configured data
M02
L
F
(M30
L
F
) User memory submodule End of data block
%PCF 1...16 PLC error message texts
N6xxx (Text)
L
F
:
N7xxx (Text)
L
F
M02
L
F
(M30
L
F
)
© Siemens AG 1991 All Rights Reserved 6ZB5 410-0HD02 2–13
