2 Fundamentals of Programming 05.91
2.7 Input/output formats
%
TOG 17...18
L
F
Simulation tool offset (TOOL OFFSET GRAPHICS)
T1 P0=...P11=...LF
T2 P0=...P11=...LF
Simulation tool data
M02
L
F
Simulation tool data - End of data block
Memory areas
The memory areas of the SINUMERIK 880 control are addressed by means of the following
identifiers:
Identifier
MPF Part program (Main Program File)
SPF Subroutine (Sub Program File)
PCF PLC error message text (PLC Files)
TOA Tool offsets (Tool Offset Active)
ZOA Zero offsets
(Zero Offset Active)
TEA1 NC machine data (Testing Data Active 1)
TEA2 PLC machine data (Testing Data Active 2)
TEA3 IAR machine data (Testing Data Active 3)
TEA4 Cycle machine data (Testing Data Active 4)
RPA R parameter numbers with value assignments
( R Parameter Active)
SEA Addresses with value assignments
(Setting Data Active)
SEA4 Cycle setting data (Setting Data Active 4)
CLF Clear statement (Clear File)
UMS User memory submodule
TOG Simulation tool data (Tool Offset Graphics)
Deleting programs
These functions permit part programs and subroutines to be deleted in any sequence via the
input/output interface.
DELETE PROGRAM Leader
%CLF
L
F
Delete program identifier (CLEAR FILE)
MPF 1234
L
F
Delete part program % 1234
MPF 1, 1200
L
F
Delete part program %1 to % 1200
MPF 0, 9999
L
F
Delete all part programs
SPF 10
L
F
Delete subroutine L10
SPF 11, 79
L
F
Delete subroutines L11 to L79
SPF 1, 999
L
F
Delete all subroutines (except cycles)
PCF 1, 9999 PLC error message
M30, M02 or M17
L
F
End identifier M30, M02 or M17
2–14
