Siemens siprotec 7SA522 User Manual

Configuration
5-6 7SA522 Manual
C53000-G1176-C119-2
132 Teleprot. E/F Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Disabled
Disabled Teleprotection for Earth fault
overcurr.
133 Auto Reclose Disabled
1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled Auto-Reclose Function
134 AR control mode Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Pickup w/ Tact Auto-Reclose control mode
135 Synchro-Check Disabled
Enabled
Disabled Synchronism and Voltage Check
137 Overvoltage Disabled
Enabled
Disabled Overvoltage
138 Fault Locator Disabled
Enabled
Enabled Fault Locator
139 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
140 TripCirc.Superv Disabled
1 trip circuit
2 trip circuits
3 trip circuits
Disabled Trip Circuit Supervision
