6.16.4 Information Overview
Hardware and
Software Supervi-
sion
General Current
Supervision
F.No. Alarm Comments
140 Error Sum Alarm Error with a summary alarm
144 Error 5V Error 5V
160 Alarm Sum Event Alarm Summary Event
177 Fail Battery Failure: Battery empty
181 Error A/D-conv. Error: A/D converter
182 Alarm Clock Alarm: Real Time Clock
183 Error Board 1 Error Board 1
184 Error Board 2 Error Board 2
185 Error Board 3 Error Board 3
186 Error Board 4 Error Board 4
187 Error Board 5 Error Board 5
188 Error Board 6 Error Board 6
189 Error Board 7 Error Board 7
192 Error1A/5Awrong Error:1A/5Ajumper different from setting
193 Alarm NO calibr Alarm: NO calibration data available
194 Error neutralCT Error: Neutral CT different from MLFB
F.No. Alarm Comments
161 Fail I Superv. Failure: General Current Supervision
162 Failure Σ I Failure: Current Summation
163 Fail I balance Failure: Current Balance
164 Fail U Superv. Failure: general Voltage Supervision
165 Fail Σ U Ph-E Failure: Voltage summation Phase-Earth
167 Fail U balance Failure: Voltage Balance
169 VT FuseFail>10s VT Fuse Failure (alarm >10s)
170 VT FuseFail VT Fuse Failure (alarm instantaneous)
171 Fail Ph. Seq. Failure: Phase Sequence
195 Fail Conductor Failure: Broken Conductor
196 Fuse Fail M.OFF Fuse Fail Monitor is switched OFF
197 MeasSup OFF Measurement Supervision is switched OFF
